Fish Paper（Green color）
Fish Paper（Green color）
Main Parameters:
Insulation class: E class (120 °C)
Color: Cyan, Brown, Blue
Width: 10-1300mm
Thickness: 0.08-0.45mm
Can be customized
Yaan Catalog Product Information
Description of Fish Paper
Fish paper is a two-layer flexible composite material, produced by B Class adhesive to adhere insulation paper with polyester film together
--Two layers: polyester film is bonded with insulating paper.
--Base Layer: 100% Sulfate wood pulp presspaper
--Outer Layer: Polyester film(PET) for Electrical Purposes
Advantages of the Fish Paper:
—Outstanding dielectric properties
—Fish paper electrical insulation has good mechanical strength because it’s fibrous
—Retains greater flexibility than plastics at low temperatures
Features of the Fish Paper:
—Width: 10-1300mm
—Thickness: 0.08-0.45mm
--Form: roll, sheet, strip
--Colur: Blue, cyan, nature brown. Special colours can be provided on request. --Three or four layers can be produced on request.
--The insulation system has been approved by UL (NO.: E310670) and the products have passed ROHS and RECH test.
Technical Parameters
| Item | Unit | Requirement | |||||||||
| Thickness | mm | 0.15 | 0.17 | 0.2 | 0.22 | 0.25 | 0.27 | 0.3 | 0.4 | 0.5 | |
| Thickness tolerance | mm | ±0.02 | ±0.03 | ±0.04 | ±0.05 | ||||||
| Density | g/m2 | 190±28 | 215±32 | 250±38 | 275±40 | 310±46 | 330±50 | 370±55 | 490±73 | 610±90 | |
| Film thickness | um | 36 | |||||||||
| Tensile Strength | MD no bending | N/10m m | ≥135 | ≥150 | ≥170 | ≥190 | ≥210 | ≥240 | ≥270 | ≥320 | ≥410 |
| MD after bending | ≥80 | ≥90 | ≥100 | ≥120 | ≥130 | ≥140 | ≥150 | ≥230 | ≥300 | ||
| TD no bending | ≥80 | ≥90 | ≥100 | ≥110 | ≥120 | ≥130 | ≥140 | ≥200 | ≥260 | ||
| TD after bending | ≥60 | ≥60 | ≥80 | ≥80 | ≥80 | ≥90 | ≥100 | ≥130 | ≥170 | ||
| Elongation | MD | % | ≥2 | ≥3 | |||||||
| （%） | |||||||||||
| TD | ≥8 | ≥10 | |||||||||
| Breakdown voltage | Not bending | kV | ≥7 | ||||||||
| After bending | ≥6 | ||||||||||
| Delamination | — | No Delamination, no bubble or other defects | |||||||||
| Affected by heat（130±2℃） 10min | No Delamination, no bubble, no adhesive flow | ||||||||||
| Long-term heat resistance | ≥120 | ||||||||||
| (temperature index TI) | |||||||||||
| Weight and area conversion | m2/Kg | 6.23 | 5.21 | 4.68 | 4.24 | 3.74 | 3.46 | 3.12 | 2.34 | 1.87 | |
FAQ
1.Q: Are you trading company or manufacturer ?
A: We are a manufacturer, We have more than 36 years experience in producing electrical insulation material.
2.Q: Where is your factory located? How can I visit there?
A: Our factory is located in Xuchang,Henan provience.
3.Q: Which certification do you have?
A: The plant has passed the certificate of ISO 9001 quality system certification;
The products have passed ROHS test.
4.Q: Can i get a samples for free?
A: Of course we can sent you a sample for free, customers just need to pay a litter shipping change.
5.Q: How long is the delivery time?
A: Generally it is 5-15 days if polyimide film price is in stock, or it is 15-30 days.
